scope of supply

The SWB-07 steering wheel leveler contains:

Diagnosis unit body VCI5

Bluetooth adapter on the computer

Metal head OBD communication line

USB port charging cable

232 serial communication line (communication with PC)

Complete technical data, including Chinese and English data booklets

Purpose of equipment

The GM Diagnostic VCI5, developed by IYASAKA (Beijing) Transportation Technology Co., Ltd., is a high-performance automotive bus data transmission device. It employs dual communication modes: wired-wireless Bluetooth and wired 232 serial port, functioning as a complete automotive network communication protocol controller with high-speed and reliable data transmission. Powered via the OBD interface, it features a wake-up capability and is widely applicable for bus diagnostics across major automakers. The device integrates four CANFD compatible interfaces, one DOIP communication port, and one K-line communication port, supporting nearly all common automotive network communication standards.

surveillance project

CANFD communication (compatible with CANBUS)

One-way DOIP communication function

1 K-LINE communication function

Functioning

Connect the cars BD cable to power the diagnostic instrument;

Supports Bluetooth wireless and 232 serial port cable transmission;

Support multiple automotive bus protocols

Supports the secondary development interface function of the host computer.

Integrated with 4 CANFD/CANBUS communication modes;

Supports 1 K bus communication mode;

pilot lamp	state	Indicating status
Power	red	Power on the device
Power	Its not bright	The device is not powered on
BT SYS	blue	Bluetooth is connected
BT SYS	Its not bright	Bluetooth is not connected
COM	Its not bright	No data transfer
COM	Green flashes	The host computer is transmitting messages to the diagnostic instrument
	Its not bright	No data transfer
OBD	Yellow flashes	The ECU is transmitting messages to the diagnostic instrument

Integrated with 1 DOIP bus communication mode;

Wireless and wired automatic switching;

The signal light indicates the working status

essential parameter

Bluetooth transmission distance: 100 meters in open space

Transmission port rate: 38400~115200

Interface: wired/wireless Bluetooth connection, serial port communication

Equipment composition

GM diagnostic instrument ——VCI5

GM diagnostic instrument —— VCI5Place of origin: ChinaManufacturing company: IYASAKA scope of supplyThe SWB-07 steering wheel leveler contains:Diagnosis unit body VCI5Bluetooth adapter on the computerMetal head OBD communication lineUSB port charging cable232 serial communication line (communication with PC)Complete technical data, including Chinese and English data bookletsPurpose of equipmentThe GM Diagnostic VCI5, developed by IYASAKA (Beijing) Automotive Technology Co., Ltd., is a high-performance automotive bus data transmission device. It employs dual communication modes: wired-wireless Bluetooth and wired 232 serial port, functioning as a complete automotive network communication protocol controller with high-speed and reliable data transmission. Powered via the OBD interface, it features a wake-up capability and is widely applicable for bus diagnostics across major automakers. The device integrates four CANFD compatible interfaces, one DOIP communication port, and one K-line communication port, supporting nearly all common automotive network communication standards.surveillance project4路CANFD communication (compatible with CANBUS)One-way DOIP communication function1 K-LINE communication functionFunctioningConnect the cars BD cable to power the diagnostic instrument;Supports Bluetooth wireless and 232 serial port cable transmission;Support multiple automotive bus protocolsSupports the secondary development interface function of the host computer.Integrated with 4 CANFD/CANBUS communication modes; Supports 1 K bus communication mode;pilot lampstateIndicating statusPowerredPower on the deviceIts not brightThe device is not powered on BTSYSblueBluetooth is connectedIts not brightBluetooth is not connected COMIts not brightNo data transferGreen flashesThe host computer is transmitting messages to the diagnostic instrumentIts not brightNo data transferOBDYellow flashesThe ECU is transmitting messages to the diagnostic instrumentIntegrated with 1 DOIP bus communication mode;Wireless and wired automatic switching;The signal light indicates the working statusessential parameterBluetooth transmission distance: 100 meters in open space Transmission port rate: 38400~115200 Interface: wired/wireless Bluetooth connection, serial port communication Equipment composition
